ข้อมูลสินค้า
- Physical protector equipped
- Physical durability improved
- Easy installation screw holes
- Easy installation lead-wire tip soldering finish
- Sticker color indication for water proof type and non-water proof type
- 2-wire system
- Alarm response lamp (LED)
- Water proof type available
- Approved by Japan Fire Equipment Inspection Institute
Specifications
Model : FDLJ906-D-65
Type : Standard
Additional Circuit : None
Sensitivity : Special
Rated Operating Temperature : 65 °C
Sensor Contact Rating : 30 VDC , 75 mA
Dry Contact Rating : None
Response Lamp : Red LED
Ambient Temperature : – 10 to 45 °C
Materials : Heat receiving plate : Aluminum
Main body : Polycarbonate resin
Weight : Approx.71g
Model : FDLJ906-DW-65
Type : Water-proof
Additional Circuit : –
Sensitivity : –
Rated Operating Temperature : –
Sensor Contact Rating : –
Dry Contact Rating : –
Response Lamp : –
Ambient Temperature : –
Materials : –
Weight : Approx.82g
Model : FDLJ106-DW-X75
Type : –
Additional Circuit : with a remote indicator lamp circuit
Sensitivity : Class 1
Rated Operating Temperature : 75 °C
Sensor Contact Rating : –
Dry Contact Rating : –
Response Lamp : –
Ambient Temperature : – 10 to 55 °C
Materials : –
Weight : Approx.85g
Model : FDLJ106-DW-S75
Type : –
Additional Circuit : with a dry contact circuit
Sensitivity : –
Rated Operating Temperature : –
Sensor Contact Rating : 30 VDC , 62 mA
Dry Contact Rating : 50 VDC , 0.1A
Response Lamp : –
Ambient Temperature : –
Materials : –
Weight : –
